Product Brochures
MedLink Brochure
MedLink™ Medication Management Cart
Improving Patient Safety, Increasing Accountability, Streamlining Workflows
The MedLink Cart is a medication management solution that ensures safe, accurate medication administration. It’s specifically designed to reduce human error, keep patients safe, and create a closed-loop medication system using lockable drawers and patient wristband scanning. This ensures each patient receives the correct medication while allowing caregivers to focus on patient care.
MedLink creates a closed-loop medication management system. First, individual drawers are loaded with medication at the pharmacy, ADC or nursing station. Then each drawer is electronically labeled assigned to a specific patient.
MedLink Pro Software
T7 MedLink™ Medication Management Cart Product Overview
T7 MedLink™ Medication Management Cart Product Overview
Key Features
- AutoFit™ Technology offers unprecedented ease of adjustment for each user in a shared work environment, providing one, simple, combined adjustment for the work surface, keyboard support, and display. MedLink’s 20” (50.8 cm) height range ensures comfortable ergonomic accommodation for seated and standing caregivers.
- Power Track™ steering, enables caregivers to easily maneuver in tight spaces and corridors, even with one-handed operation.
- The MedLink cart offers industry-leading maneuverability and one of the smallest practical footprints on the market.
- MedLink powered carts have a completely encased wire management system, which mitigates both clutter and infection control concerns.
- The ’s streamlined design makes cleaning easy and promotes a healing environment.
- MedLink’s modular system can be upgraded and adapted to suit your workflow. MedLink Housings include two removable cassettes that can be transported and exchanged while drawers remain locked and secured.
Click the buttons below to learn more
Toggle Marker
Rotates 90 degrees to allow unobstructed view while the cart is pushed and to enable on-screen content sharing with patients. It provides 15 degrees of tilt to help accommodate the use of bifocals.
Toggle Marker
Serving as a back handle for the cart and as cable management. The gantry raises the monitor providing more work surface.
Toggle Marker
Standard RFID Readers can be secured under the cover utilizing built in mounting feature.
Toggle Marker
Ample work surface space allows for greater utility.
Toggle Marker
The MedLink cart can support all-in-ones, laptops, thin clients and small form factor PCs.
Toggle Marker
The MedLink base design leaves comfortable room for full strides and toe clearance when walking.
Toggle Marker
12 different drawer kit configurations available.
Well Suited For
- Patient Triage
- Physician Rounds
- Patient Registration
- Ambulatory/Outpatient Areas
- ICU
- Operating Rooms
- Med/Surg
- Vaccination Sites
Specifications
AC POWER SYSTEM
120VAC version
• Input: 120VAC
• Output: 120VAC pure sine wave, 60Hz
• Continuous output capacity: 150W
• Peak output capacity: 225W
230VAC version
• Input: 230VAC
• Output: 230VAC pure sine wave, 50Hz
• Continuous output capacity: 150W
• Peak output capacity: 225W
BATTERY OPTIONS
Sealed Lead Acid (SLA)
• 480 W (35 Amp Hour), 12 V output
Lithium Iron Phosphate
• 45 amp hour
• 12.8 V output
• 2,000 cycles at 80% depth of discharge (DOD) ° 21⁄2 hours recharge time° Limited 5-year warranty
• Indicates charging status • Do not operate the height adjustment continuously for more than 2 minutes. After 2 minutes of continuous operation, 18 minutes of rest time should be allowed to the system. • The MedLink™ cart can accommodate max. 2 monitors weighing up to 26 lbs (11.6 kg) together. • The MedLink™ cart can accommodate a computer up to (L x W x H) 17.35” x 12.3” x 2.25” (440 mm x 312.5 mm x 57 mm) and has a 16.8” (426 mm) wide opening for a laptop screen.
BATTERY LEVEL INDICATOR
• Battery level
RECOMMENDED HEIGHT ADJUSTMENT OPERATION
MONITOR WEIGHT
COMPUTER DIMENSIONSRead More
