T7 Powered Technology Cart

Overview

Built for intuitive one-hand operation, the T7 Powered Cart is an innovation in medical technology carts. Its Auto Fit™ technology instantly adjusts to each caregiver’s entered height, while its Power Track™ steering allows for virtually effortless maneuvering and complete user control. With a beautifully simple design, the T7 makes cleaning easy and promotes a healing environment.

Key Features

  • AutoFit™ Technology offers ease of adjustment for each user in a shared work environment, providing one simple combined adjustment for the work surface, keyboard support, and display.
  • The 20” (50.8 cm) height range ensures comfortable ergonomic accommodation for seated and standing caregivers.
  • Power Track™ steering enables caregivers to easily maneuver in tight spaces and corridors, with one-handed operation.
  • T7 Powered Carts have a completely encased wire management system, which mitigates both clutter and infection control concerns.
  • Streamlined design makes cleaning easy and promotes a healing environment.

Well Suited For

  • Patient Triage
  • Physician Rounds
  • Patient Registration
  • Ambulatory/Outpatient Areas
  • ICU
  • Operating Rooms
  • Med/Surg
  • Vaccination Sites

Specifications

  • Cart Specifications
  • Battery Specifications

AC POWER SYSTEM

120VAC version
• Input: 120VAC
• Output: 120VAC pure sine wave, 60Hz
• Continuous output capacity: 150W
• Peak output capacity: 225W

230VAC version
• Input: 230VAC
• Output: 230VAC pure sine wave, 50Hz
• Continuous output capacity: 150W
• Peak output capacity: 225W



RECOMMENDED HEIGHT ADJUSTMENT OPERATION

• Do not operate the height adjustment continuously for more than 2 minutes. After 2 minutes of continuous operation, 18 minutes of rest time should be allowed to the system.



MONITOR WEIGHT

• The T7 can accommodate max. 2 monitors weighing up to 26 lbs (11.6 kg) together.



COMPUTER DIMENSIONS

• The T7 can accommodate a computer up to (L x W x H) 17.35” x 12.3” x 2.25” (440 mm x 312.5 mm x 57 mm) and has a 16.8” (426 mm) wide opening for a laptop screen.

T7 Powered Technology Cart Specifications
